Cassette-Geko FAN COIL UNIT

Compact fan coil unit with high cooling capacity for comfort air treatment.
  • Low noise level
  • Low energy consumption
  • Easy installation and service friendly
  • Cooling with chilled water
  • 3 unit sizes with up to 3 capacitiy stages
  • Air flow range 250 – 1520 m3/h
  • Cooling capacity from 1.5 – 10.5 kW and heating capacity from 2.2 – 18.6 kW
  • 2-pipe system: 2 or 3 rows (cooling or heating) for Single Cassette and 3 rows for Big Single and Double version (cooling or heating)
  • 4-pipe system: 2+1 rows for cooling and heating
  • EC-Fan for low energy consumption
  • Single model with 575 x 575 mm casing, 660 x 660 mm covering discharge panel
  • Double model with 1175 x 575 mm casing, 1260 x 660 mm covering discharge panel
  • Big Single model with 822 x 822 mm casing, 905 x 905 covering discharge panel
  • Certified performance by EUROVENT certification

Brug for hjælp?

Få rådgivning og support til projekter

Kontakt os

Units are in beautiful timeless design with 3 sizes (Single, Big Single, Double) and equipped with up to 3 capacity stages, high control flexibility and easy maintenance. Cassette-Geko chilled water unt is the result of an extended design development. It combines high performances, silent operation and high quality components. The air diffuser is available in two different aesthetical appearances, a white ASA outlet panel with 4-way louvers either in white (RAL 9003) or light grey (RAL 7035).

Every unit can be supplied with a cooling water coil, heating water coil or electrical heater. The Cassette-Geko can have primary air intake and a remote air diffuser can be connected to the unit. The integrated condensate pump is very quiet and has a max. head of 1.3 m. Green Tech EC fans with continuous operational range grant highest efficiency with energy savings up to 85% in part-load operation. External failure signal for status control of the fan(s) are available. Controls is driven by GreenTech fan technology and provides best fan coil operation.
